Used7CASE 570ST Backhoe Loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this machine
This Case TCA8040.45 is listed by AHS Group at NSW.
As listed, it has a CARRARO 2WD TLB1 or 4WD TLB1 transmission.
AHS Group has not published a price for this machine — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Case |
| Model | TCA8040.45 |
| Condition | Used |
| Name | 570ST |
| Model Code | TCA8040.45 |
| Bore / Stroke | 104 mm x 115 mm |
| Displacement / Compression ratio | 3.9 l / 18.3:1 |
| Engine Power (ISO 14396) @2200 rpm | 97 hp |
| Maximum torque (ISO 14396) | 420 Nm |
| Engine speeds | 2200 rated speed, full load, 950 low idle speed (at no load) |
| Transmission | CARRARO 2WD TLB1 or 4WD TLB1 |
| Model | CARRARO 4WD TLB1 (for 570T/ST 4WD) |
| Type | Closed center with double gear pump |
| Gear | Forward - Reverse (speed kmph) |
| 1st - 2nd - 3rd - 4th | 7.4 - 12 - Not recom. - Not recom |
| 2 Wheel Drive (Standard) | Model CNH PS1300 |
| Type - Oscillation | Steering - +/- 8 ° |
| 4 Wheel Drive (Optional) | Model CARRARO 26.17 |
| Model for 570T 2WD and 4WD | CARRARO 28.32M |
| Service brakes | Type: wet multi-discs / Nr. of discs: 6 |
| Parking brakes | Type: Manual, with lever |
| System pressure / Displacement | 140 bar / 125 cc |
| Turning radius (outside of the bucket) | 5550 mm without brake |
| Tread width | 1697 mm rear |
| 2WD | 16.9 x 28 - 12PR or 14 x 25 - 20PR rear |
| 4WD | 16.9 x 28 - 12PR rear |
| Flow rate | 145 lpm @ 2200 rpm |
| Pressure | 210 bar |
| Engine oil | 13.6 l |
| Transmission oil 2WD/4WD | 20.8 l |
| Front axle 4WD oil | 11.8 l |
| Rear axle oil | 12.3 l |
| Hydraulic oil | 132 l |
| Fuel tank | 132 l |
| Coolant | 24 l |
| Voltage | 12 V |
| Battery | Single: 95 Ah 900 A or Double: 60 Ah, 600 A (each) |
| Alternator | 120 A |
| Certification | ROPS / FOPS |
| Air Conditioning | Optional |
| Storage compartments capacity | 45 l including: 2 lockable, cooling box |
| Speedometer | Optional |
| Bluetooth radio | Optional |
| Internal (cab) | 77 dB(A) |
| External | 103 dB(A) |
| Location | NSW |
| Category | Backhoes |
The CASE 570ST Backhoe Loader delivers 97 HP of dependable power with strong hydraulics, extendable digging reach, and a straight-arm loader for faster cycles. Built for reliabilit… Full description on the dealer's site →
