Home / Search / Rollers / FPT CASE 1110EX-D Single Drum Roller

FPT CASE 1110EX-D Single Drum Roller

AHS Group·NSW
3 photos supplied by AHS Group and displayed from their website. See the original listing →

About this roller

This FPT S8000 - TIER lII is listed by AHS Group at NSW.

AHS Group has not published a price for this roller — it is listed as price on application, so you will need to contact them for a figure.

Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.

Specifications

MakeFPT
ModelS8000 - TIER lII
ConditionUsed
Name1110EX-D
MakeFPT
ModelS8000 - TIER lII
TypeVariable displacement bi-directional axial piston pump with manual displacement control
Cylinders4
Bore/stroke104 x 115
Displacement3.9 L
Fuel injectionDirect
FuelHigh speed diesel
Fuel filterSpin-on type
Air intakeTurbocharged with internal EGR
Air filterReplaceable dry type with dual element & coupled with turbo pre-cleaner
Engine oil filterSpin-on type
CoolingLiquid
Engine speeds (no load) - Low (±50)950 rpm
Engine speeds (no load) - High (±25)2,150 rpm
Max. power (ISO14396)110 hp
Max. torque (ISO14396)430 Nm
Drive to vibration pumpMechanical
Engine to pump ratioDirect drive 1:1
Vibration motorFixed displacement mounted on drum
Steering systemHydraulic assisted articulated
Steering angle37 °
Turning radius (inner radius)3.42 m
Drum oscillation angle15 °
Tyre size23.1/26
Alternator output (with/without cab)65 A/105 A
Batteryexide, 12V/ 130Ah
Fuel tank235 L
Hydraulic tank70 L
Engine crank9.1 L
Engine coolant15 L
Drive pumpMechanical
Displacement (cc/Rev)78
Flow @2200 RPM171
Charge pressure @1800rpm22 bar
Drive motors - Drum driveRadial piston motor, fixed displacement mounted on drum
Drive motors - Parking brakeSpring applied hydraulically released
Drive motors - EngagementOperate on /off parking brake switch on instrument panel, engine stop
Machine speed - Working speed0-5.5 km/h
Machine speed - Travel speed0-11.5 km/h
Gradeability - With drum drive36 %
Gradeability - Intermittent40 %
LocationNSW
CategoryRollers

The CASE 1110EX-D delivers 110 HP of reliable power with an advanced drum drive, superior traction, and smooth hydrostatic control. Built for long shifts and heavy workloads, it of… Full description on the dealer's site →
