New2CASE CX17D Excavator

About this excavator
AHS Group has this Case CX17D Excavator available at NSW.
AHS Group has not published a price for this excavator — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Case |
| Model | CX17D Excavator |
| Condition | Used |
| Name | CASE CX17D |
| Type | YANMAR 3TNV70 - STAGE 5 |
| Max. Power | 16.1 HP |
| Displacement | 854 cm³ |
| Number of cylinders | 3 n° |
| Cooling | Liquid |
| Consumption | 2.4 l/h |
| Alternator | 12 V |
| Battery | 12 V |
| Pump type | variable flow |
| Pump displacement | 8 + 8 + 6.6 cm³ |
| Pump capacity | 16 + 16 + 13.1 l/min |
| Max circuit calibration pressure bar | 220 |
| Auxiliary system (max pressure): AUX 1 | single or double effect 29.1 - 205 l/min (bar) |
| Auxiliary system (max pressure): AUX 2 | optional 13.1 - 205 l/min (bar) |
| Auxiliary system (max pressure): AUX 3 | optional 16 - 220 l/min (bar) |
| Travelling speed (AUTO TWO SPEED) | 1st : 0 ÷ 2.2 / 2nd : 0 ÷ 4.1 km/h |
| Slew speed | 10.5 RPM |
| Dozer blade | Pilot lever |
| Auxiliary system: AUX 1 | Right pedal |
| Auxiliary system: AUX 2 | - |
| Boom swing | Left pedal |
| Transport weight with canopy | 1,580 Kg |
| Transport weight with cab | 1,690 Kg |
| Operating weight with canopy | 1,690 Kg |
| Operating weight with cab | 1,800 Kg |
| Fuel tank | 25 Litres |
| Hydraulic oil tank | 20 Litres |
| Hydraulic circuit capacity | 29 Litres |
| Cooling system capacity | 4.5 Litres |
| Engine oil | 2.4 Litres |
| Location | NSW |
| Category | Excavators |
Learn more about the CASE CX17D Mini Excavator at AHS Group. Featuring a 16.1 hp engine, 2,220 mm digging depth, and an extendable undercarriage (990 mm to 1,250 mm), this D-Series… Full description on the dealer's site →
Comparable listings in our index
4 listings for Case, ranging $79,500 to $179,990, median $97,500. These are dealer asking prices, not achieved sale prices.
