Used5FPT NEF - F4HE0484G CASE 580SV Backhoe Loader
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this machine
A FPT NEF - F4HE0484G FPT NEF - F4HE0484G offered by AHS Group in NSW.
AHS Group has not published a price for this machine — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | FPT NEF - F4HE0484G |
| Model | FPT NEF - F4HE0484G |
| Condition | Used |
| Name | 580SV |
| Make and Model | FPT NEF - F4HE0484G |
| Injection system | High Pressure Common Rail |
| Emissions level | Tier 3 |
| Cylinders | 4 |
| Bore / Stroke | 104 mm x 132 mm |
| Displacement / Compression ratio | 4.5 ltr / 17.5 to 1 |
| Engine Power (ISO 14396) @2200 rpm | 72 kW (96.6 hp) |
| Maximum torque (ISO 14396) | 453 Nm |
| Engine speeds | 2200 rpm (rated speed at full load) / 950-1000 rpm (low speed at no load) |
| Type | Load sensing, closed center hydraulic system with twin gear pump |
| Model | Carraro 28.44FR with Differential lock |
| Forward travel speeds (kph) | 6 - 10 - 21 - 40 |
| Reverse travel speeds (kph) | 7 - 12 - 26 - 47* |
| Oscillation | +/- 11° |
| Service brakes | Hydraulic foot operated, 2 discs per side |
| Parking brakes | Mechanically actuated wet brake pack on transmission output shaft |
| System pressure / Displacement | 180 bar / 160 cc |
| Front | 18” or 20” |
| Rear | 26” or 28” or 30” |
| Flow (@ 2200 rpm) | 156 l/min / 15 to 165 l/min |
| Pressure | 205 bar |
| Engine oil | 13.6 l |
| Transmission oil 2WD/4WD | 20.8 l |
| Front axle 4WD oil | 9.6 l |
| Rear axle oil | 16.3 l |
| Hydraulic oil | 132 l |
| Fuel tank | 132 l |
| Coolant | 24 l |
| Voltage | 12 V |
| Battery | Single: 95 Ah 900 A or Double: 60 Ah, 600 A (each) |
| Alternator | 120 A |
| Certification | ROPS / FOPS |
| Air Conditioning | Optional |
| Storage compartments capacity | 45 l including: 2 lockable, cooling box |
| Speedometer | Optional |
| Bluetooth radio | Optional |
| Internal (cab) | 77 dB(A) |
| External | 102 dB(A) |
| Location | NSW |
| Category | Backhoes |
The CASE 580SV Backhoe Loader delivers strength, precision, and comfort in one machine. With powerful hydraulics, advanced control systems, and all-terrain stability, it’s built fo… Full description on the dealer's site →
