Used12Track Loader SVL97-2
AHS Group·NSW
12 photos supplied by AHS Group and displayed from their website. See the original listing →
About this skid steer
This Track Kubota V3800-TIEF4 is listed by AHS Group at NSW.
As listed, it has a done configuration.
AHS Group has not published a price for this skid steer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Track |
| Model | Kubota V3800-TIEF4 |
| Condition | Used |
| Name | SVL97-2 |
| Engine Type | Tier 4 Emission Level |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Engine Model | Kubota V3800-TIEF4 |
| Engine Net | 87 HP |
| Engine Gross | 96.4 HP |
| Displacement | 3,769 cc |
| Rated Speed | 2,400 rpm |
| Track Width - Standard | 450 mm |
| Ground Pressure Cab - Standard Track | 4.5 psi |
| Track Roller (Per Side) | 5 |
| Track Ground Contact Length | 1,667 mm |
| Traction Force | 5,524 kg |
| Min. Ground Clearance | 293 mm |
| Aux Hydraulic Flow - High | 152 l/min |
| Loader Hydraulic Pressure (Per cm2) | 249.8 kgf |
| ROC - 35% Tipping Load | 1,451 kg |
| Tipping Load | 4,147 kg |
| Breakout Force - Bucket | 3,458 kg |
| Breakout Force - Lift Arm | 2,509 kg |
| Lift Arm Path | Vertical |
| Low | 8 km/h |
| High | 11.7 km/h |
| Length | 3,137 mm |
| Width - Standard Track | 1,962 mm |
| Height | 2,116 mm |
| Operating Weight - Cab | 5,240 kg |
| Fuel Reservoir | 109 l |
| Hydraulic System | 68 l |
| Hydraulic Tank | 38.1 l |
| Cab | done |
| Open Cab | close |
| Front Sliding Window | done |
| Location | NSW |
| Category | Skid Steers |
Powered by a 96.4HP Kubota engine with exceptional 3611KG bucket breakout force and outstanding lifting capacity at 2662KG, the Kubota SVL97-2 delivers superior comfort and perform… Full description on the dealer's site →
