Used12Track Loader SVL97-3
AHS Group·NSW
3 photos supplied by AHS Group and displayed from their website. See the original listing →
About this skid steer
AHS Group has this Track Kubota V3800-TIEF4 available at NSW.
As listed, it has a done configuration.
AHS Group has not published a price for this skid steer — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Track |
| Model | Kubota V3800-TIEF4 |
| Condition | Used |
| Name | SVL97-3 |
| Engine Type | Water Cooled |
| Fuel Type | Diesel |
| Cylinders | 4 |
| Engine Model | Kubota V3800-TIEF4 |
| Engine Net | 85.2 HP |
| Engine Gross | 96.4 HP |
| Displacement | 3,769 cc |
| Rated Speed | 2,500 rpm |
| Track Width - Standard | 450 mm |
| Ground Pressure Cab - Standard Track | 4.7 psi |
| Track Roller (Per Side) | 5 |
| Track Ground Contact Length | 1,667 mm |
| Traction Force | 5,976 kg |
| Min. Ground Clearance | 278 mm |
| Aux Hydraulic Flow - High | 156 l/min |
| Loader Hydraulic Pressure (Per cm2) | 249.8 kgf |
| ROC - 35% Tipping Load | 1,569 kg |
| Tipping Load | 4,483 kg |
| Breakout Force - Bucket | 3,468 kg |
| Breakout Force - Lift Arm | 2,394 kg |
| Lift Arm Path | Vertical |
| Low | 8.9 km/h |
| High | 13.5 km/h |
| Length | 3,141 mm |
| Width - Standard Track | 1,962 mm |
| Height | 2,112 mm |
| Operating Weight - Cab | 5,411 kg |
| Fuel Reservoir | 115.7 l |
| Hydraulic System | 70 l |
| Hydraulic Tank | 40.2 l |
| Cab | done |
| Open Cab | close |
| Front Sliding Window | done |
| Location | NSW |
| Category | Skid Steers |
The newly introduced SVL97-3 takes the place of the established SVL97-2 and is Kubota Full description on the dealer's site →
