Kubota KX033-4 Compact Excavator | Powerful
AHS Group·NSW
7 photos supplied by AHS Group and displayed from their website. See the original listing →
About this excavator
AHS Group has this Kubota Kubota D1703M available at NSW.
AHS Group has not published a price for this excavator — it is listed as price on application, so you will need to contact them for a figure.
Full photos, the dealer's own description and any additional detail are on AHS Group's website. Specifications shown here are as published by the dealer and are not independently verified — confirm hours, condition and GST treatment before you commit.
Specifications
| Make | Kubota |
| Model | Kubota D1703M |
| Condition | Used |
| Name | KX033-4 |
| Engine Type | Interim Tier 4 Emission Level |
| Fuel Type | Diesel |
| Cylinders | 3 |
| Engine Model | Kubota D1703M |
| Engine Net | 23.9 HP |
| Engine Gross | 24.8 HP |
| Displacement | 1,647 cc |
| Rated Speed | 2,200 rpm |
| Max. Traction Force | 2,763 kgf |
| Tumbler Distance | 1,665 mm |
| Crawler Length | 2,100 mm |
| Shoe Width | 300 mm |
| Ground Contact Pressure - Cab (Per cm2) | 0.321 kgf |
| Hydraulic Pump Capacity | 39.6 variable x 2 / 20.9 Gear x 1 l/min |
| Aux Hydraulic Flow - AUX1 | 60 l/min |
| Max. Breakout Force - Bucket | 3,694 kgf |
| Max. Breakout Force - Arm | 1,756 kgf |
| Swing System | Conventional Swing |
| Unit Swing Speed | 8.9 rpm |
| Boom Swing Angle Left | 70 degree |
| Boom Swing Angle Right | 48 degree |
| Low | 3 km/h |
| High | 4.6 km/h |
| Length | 4,730 mm |
| Width | 1,550 mm |
| Height - Canopy | 2,480 mm |
| Height - Cab | 2,470 mm |
| Min. Ground Clearance | 290 mm |
| Operating Weight - Canopy | 3,365 kg |
| Operating Weight - Cab | 3,511 kg |
| Max. Blade Width | 1,550 mm |
| Blade Height | 345 mm |
| Max. Lift Above Ground | 365 mm |
| Max. Drop Below Ground | 375 mm |
| Fuel Reservoir | 46.9 l |
| Hydraulic Oil Reservoir | 44.6 l |
| Hydraulic Oil System | 61 l |
| Engine Oil | 5.3 l |
| Operator Station | Canopy |
| Max. Digging Height | 4,980 mm |
| Max. Dumping Height | 3,530 mm |
| Max. Digging Depth | 3,210 mm |
| Max. Vertical Digging Depth | 2,235 mm |
| Max. Digging Radius At Ground | 5,120 mm |
| Max. Digging Radius | 5,230 mm |
| Min. Turning Radius - w/o Swing | 2,020 mm |
| Min. Turning Radius - Swing | 1,510 mm |
| Min. Tail Turning Radius | 1,250 mm |
| Location | NSW |
| Category | Excavators |
Get the job done with the Kubota KX033-4 compact excavator, designed for superior digging and durability. Explore mini excavators for sale now! Full description on the dealer's site →
